Powerlift 200 | Residential & Commercial Dumbwaiter

UL Listed Elevator/Dumbwaiter controller. (UL#233908)

CARRYING CAPACITY: 200 lbs

MAXIMUM CAR SIZE: 30″ x 30″ x 30″ High
(max clear inside car is 28” x 28” x 28”)

NOTE: Maximum car sizes quoted are based on a cubic inch equation, but the width, depth and height dimensions are customizable within that equation. For example, you can choose a car size of 20″ x 24″ by 34″ High, usually at no additional charge.

**Discuss Car options with your Project Manager**

INSTALLATION: Dumbwaiter installs in hours, not days.

WARRANTY: 3 year commercial and 5 year residential warranties.

INCLUDED:

• ​Call / send buttons, door locks, and door safety switches
• Powder-coated rail assembly, trolley, and car

MOTOR OPTIONS:

• Bottom or top motor mount.
• 3/4 HP – 110 volt motor.​
• 220V – 3/4 HP motor available.
• ​240 volt – 3/4 HP 50 Hz motors for European markets available.

UNIT OPTIONS:

• ​​Stainless steel units available.
• Floor loading units available.

CAR OPTIONS:

• Dumbwaiter car can be open on any of 3 sides, except where the rails are mounted, at no additional charge.
• ​Powder-coated car panels available.
• Stainless steel cars available.
• ​Adjustable car shelves available. (Not available with car gate.)
• ​Removable car shelves available.
• In car dome light available.

GATE & DOOR OPTIONS:

• Slide-up and bi-parting car gates available.
• ​Stainless steel motor access panel and hoistway doors available.

CALL STATION OPTIONS:

• Car here lights available.
• Designer push button plates available.

SAFETY FEATURES:

• Adjustable limits.
  NOTE: The limits are preset to your specs, but are easily adjustable in your home.
• ​All low voltage wiring is prewired with quick-connect plugs for easy installation.
• ​Size 40 roller chain. (3125 lbs tensile breaking strength)
• ​Top and bottom final limits available.
• ​ASME 17.1 package available.
• ​Elevator interlocks available.
• Pillow block top fixture.

Powerlift 200 | Residential & Commercial Dumbwaiter

UL Listed Elevator/Dumbwaiter controller. (UL#233908)

CARRYING CAPACITY: 200 lbs

MAXIMUM CAR SIZE: 30″ x 30″ x 30″ High
(max clear inside car is 28” x 28” x 28”)

NOTE: Maximum car sizes quoted are based on a cubic inch equation, but the width, depth and height dimensions are customizable within that equation. For example, you can choose a car size of 20″ x 24″ by 34″ High, usually at no additional charge.

**Discuss Car options with your Project Manager**

INSTALLATION: Dumbwaiter installs in hours, not days.

WARRANTY: 3 year commercial and 5 year residential warranties.

INCLUDED:

• ​Call / send buttons, door locks, and door safety switches
• Powder-coated rail assembly, trolley, and car

MOTOR OPTIONS:

• Bottom or top motor mount.
• 3/4 HP – 110 volt motor.​
• 220V – 3/4 HP motor available.
• ​240 volt – 3/4 HP 50 Hz motors for European markets available.

UNIT OPTIONS:

• ​​Stainless steel units available.
• Floor loading units available.

CAR OPTIONS:

• Dumbwaiter car can be open on any of 3 sides, except where the rails are mounted, at no additional charge.
• ​Powder-coated car panels available.
• Stainless steel cars available.
• ​Adjustable car shelves available. (Not available with car gate.)
• ​Removable car shelves available.
• In car dome light available.

GATE & DOOR OPTIONS:

• Slide-up and bi-parting car gates available.
• ​Stainless steel motor access panel and hoistway doors available.

CALL STATION OPTIONS:

• Car here lights available.
• Designer push button plates available.

SAFETY FEATURES:

• ​Adjustable limits.
  NOTE: The limits are preset to your specs, but are easily adjustable in your home.
• ​All low voltage wiring is prewired with quick-connect plugs for easy installation.
• ​Size 40 roller chain. (3125 lbs tensile breaking strength)
• ​Top and bottom final limits available.
• ​ASME 17.1 package available.
• ​Elevator interlocks available.
• Pillow block top fixture.

Get Your Powerlift 200 Dumbwaiter Today
